Physics MCQs

Notes:
A Venturimeter is the device used to measure rate of flow of fluids. This device is based on the principle of Bernoulli’s Equation.

Notes:
The north pole of a magnet in a compass points north because it is attracted to the Earth’s magnetic south pole, which is located near Earth’s geographic north pole. The geographic north pole of earth corresponds to magnetic south pole and geographic south pole of earth corresponds to magnetic north pole. The direction in which a compass needle points is known as magnetic north. This is not exactly the direction of the North Magnetic Pole. Instead, the compass aligns itself to the local geomagnetic field, which varies in a complex manner over the Earth’s surface. The angular difference between magnetic north and true north (defined in reference to the Geographic North Pole), at any particular location on the Earth’s surface, is called the magnetic declination. Most map coordinate systems are based on true north, and magnetic declination is often shown on map legends so that the direction of true north can be determined from north as indicated by a compass.

Notes:
X-ray crystallography helps to determine the atomic and molecular structure of a crystal. The crystalline structure performs the diffraction and it causes a beam of incident X-rays to diffract into many specific directions.

Notes:
VHF (Very High Frequency) omnidirectional radio range (VOR), is a short-range radio navigation system for aircraft, enabling aircraft to determine their position and stay on course by receiving radio signals transmitted by a network of fixed ground radio beacons, with a receiver unit. Uses radio frequencies in the very high frequency (VHF) band from 108 to 117.95 MHz. VOR is the standard air navigational system in the world, used by both commercial and general aviation.

Notes:
The speed of sound in a medium depends on temperature of the medium. The speed of sound decreases when we go from solid to gaseous state. In any medium as we increase the temperature the speed of sound increases.. The speed of sound will be highest in humid air at 30°C.

Notes:
The motion of a projectile is two dimensional motion consisting of (i) horizontal motion and (ii) vertical motion. Hence, at any instant, the velocity of a projectile has two components (i) horizontal component and (ii) vertical component. The horizontal component remains unchanged throughout the flight as there is no acceleration in horizontal direction. The vertical component is continuously affected by the force of gravity. Thus, the horizontal motion is uniform motion but the vertical motion is uniformly accelerated motion.)

Notes:
In the presented choices, the Fermi stands as the smallest unit of length measurement. It is equal to 10^-15 m. Comparatively, 1 Micron equals 10^-6 m, 1 Nanometer equals 10^-9 m, and 1 Angstrom equivalent to 10^-10 m. All these units are commonly used to measure minuscule distances, particularly in the realm of nanotechnology and particle physics. However, the Fermi, named after the esteemed physicist Enrico Fermi, remains the smallest.

Notes:
A projectile will achieve maximum horizontal range when it is projected at an angle of 45°. This concept of maximum horizontal range is used by athletes in long jump, javelin throw, cricket ball throw etc

Notes:
When one body is actually moving over the surface of other body, the friction is known as Kinetic friction. It is also known as dynamic friction.

Notes:
The unit of intensity of Gravitational field in the c.g.s system is dyne g^-1 or cm s^-2. S.I. unit of intensity of Gravitational field is N Kg^-1 m s^-2.
